Machine size (mm):     310*310*97
Carton size (mm):      330*360*1000
20' container capacity:      224pcs
40' container capacity:      462pcs

1, General description

◇ Fuse box: Concentrated function keys on the left

◇ Side panel; design for the protection from children’s

◇ potential accident

2, Specification

◇ Colors available: White, or Grey (other colors on custom order)

◇ Cooling Way: Compressor on the bottom

◇ Voltage: 110V/60HZ 220V/50HZ

◇ Power: heating 425W, cooling 85W

◇ Fuse for cooling（hot&cold）12AMP; (cook&cold) 6AMP

◇ Compressor refrigerant: R134A

◇ Heating method: internal heating/outside heating/bottom heating

◇ Hot tank capacity：2L  5L/H ≥90℃

◇ Cold tank capacity: 4L  Cooling speed: 2L/H ≤10℃

◇ Cold tank size: 156MM (DIA) X 185MM (H)

◇ Thickness for all metal sheet：1.0MM

◇ Thickness for SS hot tank and cold tank：0.5MM

◇ Material for hot tank and cold tank: SS 304

◇ Thickness for SS baffle: 0.5MM

◇ All tube touch water:  Stainless Steel

◇ Metal connector and drain valve

◇ Removable power plug (optional)

◇ Removable drip tray

◇ Metal back handle

◇ Cold water temp- 5℃(within30-45minutes)

◇ Hot water temp- 89℃（adjustable）

◇ Certificate: CE/SASO
